The eco-solvent printer UD-181LA / UD-1812LA is our answer to Roland, Mutoh, and Mimaki. Would you like to own a top-tier machine without the astronomical price tag? Does cartridge ink seem redundant to you? Look no further. We have your solution-the Phaeton Galaxy series.
| Model | UD-181LA | UD-1812LA | |
| Print Head | Epson DX5 | ||
| Number of Print Head | 1 head | 2 heads | |
| Max Printing Width | 1800mm | ||
| Printing Speed | Draft | 4 pass 16 sqm/hour | 4 pass 31 sqm/hour |
| Standard | 6 pass 11 sqm/hour | 6 pass 21 sqm/hour | |
| Quality | 8 pass 9 sqm/hour | 8 pass 13 sqm/hour | |
| High Quality | 8 pass 9 sqm/hour | 8 pass 13 sqm/hour | |
| Backlit | 12 pass 5 sqm/hour | 12 pass 8 sqm/hour | |
| Ink | Type | Water-based / Eco Solvent Ink | |
| Color | C M Y K | ||
| Capacity | 1 liter | ||
| Ink supply system | Auto ink supply system | ||
| Media | Width | Max 1830mm | |
| Type | Vinyl, film, polyester, flex, backlit film, PS board, KT board, PVC foam board… | ||
| Auto Media Feeding System | Equipped Max media weigh 25kgs | ||
| Auto Cleaning System | Anti-clogged flash function and capping system | ||
| Pre-heating & Drying System | Equipped | ||
| Clamp | Equipped | ||
| Print Interface | USB 2.0 | ||
| Print Head Height | 2 -10mm from media | ||
| Rip Software | Ultraprint, Maintop, Photoprint, Shiraz , Wasatch | ||
| Input Power | AC220v, 50HZ/60HZ | ||
| Machine Dimension | L3080 * W990 * H 1260mm / 204kgs | ||
| Package Dimension | L3190 * W1100 * H 845mm / 400kgs | ||
High Resolution
This eco solvent printer adopts same print head as Roland, Epson DX5 print head with 24.5mm width and 8 lines nozzles. And every line contains 180 nozzles, 1440 nozzles in total. The nozzle size only is 3.5pl. It has the same resolution and printing performance as Roland eco solvent printers.
High Speed
The DX5 print head features high currency frequency, which translates to high ink-spray speed and ergo high printing speed. The responsive USB 2.0 data port further enhances processing time while enabling long scale output printing.
High Stability
Phaeton Galaxy eco solvent printers are equipped with XY AC servo motors. Precise gear-occlude with direct transmission guarantees accurate re-positioning even under high speed conditions. These printers implement the THK guide rail, famous for its stability; it is free of deformations even after a long run.
Low Printing Cost
In comparison with original cartridge ink, our bulk ink supply system is much more economical. The Galaxy printer is appreciated by advertising professionals for its long-term cost reduction benefits.
Low Maintenance
Intelligent cleaning and water-retaining equipment protects the print head while allowing for easy maintenance.
Application
The Phaeton Galaxy eco solvent printer is ideal for both indoor and outdoor printing purposes. It is compatible with printing media such as mesh, vinyl, banner, vehicle wrap, window film, photo paper, oil canvas, and perforated vinyl.
